Type 29-AS. Semi-micro, suction outlet
- Two polished windows.
- Inlet/outlet tubes - 2 I.D, 4 O.D, 10mm long intended for push-on flexible tubing.
- Funnel supplied with cell.
Type 47 Flow cells. In-line
- Two polished windows
- Profiled inlet and outlet
Type 71 & 72 F Flow cells. Standard and semi-micro
- Long sample compartment suitable for all Z dimensions.
- Inlet/outlet tubes - 2 I.D, 4 O.D, 16mm long intended for push-on flexible tubing.
Type 71, 71B, 72 & 72B Flow cells. Standard and semi-micro
- Long sample compartment suitable for all Z dimensions.
- Inlet/outlet tubes - 2 I.D, 4 O.D, 16mm long intended for push-on flexible tubing.
Type 74.4 Flow cells. Dissolution. Short path length, long aperture
- Two polished windows
- Path lengths of 0.5mm or less incorporate by-pass tubes to avoid back pressure and assist laminar flow through the sample compartment. Profiled sample compartment to optimise flow characteristics, reduces carry-over and bubble retention.
- Inlet/outlet tubes - 2 I.D, 4 O.D, 10mm long intended for push-on flexible tubing.
Types UTWA & UTWA2. Ultra thin wall aperture cells
- Two polished windows.
- Ultra thin Aperture window - 0.2mm (200 microns)
- For use with high magnification systems.
- UTWA/2 has two thin window apertures, one in each window.
